AKW Braddan 1500x700mm Level Access Shower Tray & Gravity Waste (16495W)

AKW Braddan 1500x700mm Level Access Shower Tray with Gravity Waste (Code 16495W)

The AKW Braddan 1500x700mm is one of the longest narrow trays in the Braddan range, offering a full 1500mm showering length in a space-efficient 700mm footprint. The extended length makes it ideal for taller users and purpose-built accessible bathrooms, while the slim 700mm depth keeps the overall floor area to a minimum — making it particularly well suited to corridor-style bathrooms, galley wet rooms, and adapted properties where wall length is available but width is restricted.

Made from durable GRP with integral reinforcement, the Braddan supports up to 190.5kg (30 stone) and features a slip-resistant surface as standard. At just 40mm high, it can be surface mounted for a low step-in threshold, semi-recessed for a 20mm threshold, or fully recessed into the floor for complete level access — making it suitable for the full range of domestic and accessibility projects.

No under-tray foaming is required, keeping installation clean and straightforward. The non-handed design works for both left and right-hand layouts. Tiling upstands are included as standard to ensure a watertight finish between the tray and wall tiles. Optional 20mm and 40mm ramp kits are available for semi-recessed or surface-mounted installations.

This pack includes a TDTW 50 White ABS Plastic Gravity Waste (Code 25126), which features a built-in filter, secure 50mm threaded fitting, and 124mm depth below tray.

Key Specifications:

• Size: 1500 × 700mm
• Material: GRP (Glass Reinforced Plastic)
• Height: 40mm
• Threshold: 0mm (recessed), 20mm (semi), or 40mm (surface mounted)
• Waste Position: Central
• Fall to Waste: 35mm
• Load Capacity: 190.5kg (30 stone)
• Floor Types: Timber, concrete, screeded
• Tiling Upstands: Included
• Warranty: Lifetime guarantee

What's Included:

• 1 × AKW Braddan 1500×700mm Shower Tray (Code 16495)
• 1 × TDTW 50 White ABS Plastic Gravity Waste (Code 25126)

Frequently Asked Questions

How does the 1500x700mm compare to the 1420x700mm Braddan? Both share the same slim 700mm depth, but the 1500mm adds an extra 80mm of length over the 1420mm — useful for taller users or where a longer wall run is available. It's the longest narrow-depth tray in the Braddan range, making it the top choice where maximum showering length is the priority.

Can this tray be used for full level access? Yes — when fully recessed into the floor it creates a 0mm threshold, suitable for wheelchair users and DDA-compliant installations.

Is under-tray foaming required? No, the Braddan's design eliminates the need for under-tray foaming entirely.

Can I fit a different waste to this tray? Yes. The Braddan is compatible with AKW's full range of gravity and pumped waste options. An upward discharge pumped waste is also available for installations where the floor cannot be breached.

Is it compatible with AKW shower screens? The 1500x700mm Braddan is compatible with AKW Standard, Silverdale, Sliding, Level Best, and Larenco screen ranges.

What is the warranty? The AKW Braddan carries a lifetime guarantee (terms and conditions apply).

📄 Download AKW Braddan Specification Sheet
