AKW Braddan 1200x650mm Level Access Shower Tray & Gravity Waste (16360W)

AKW Braddan 1200x650mm Level Access Shower Tray with Gravity Waste (Code 16360W)

The AKW Braddan 1200x650mm is a long, narrow shower tray designed for bathrooms and wet rooms where wall length is generous but floor width is restricted. At 1200mm long and just 650mm wide, it's one of the slimmest options in the Braddan range — making it particularly well suited to narrow en-suites, adapted bathrooms in older properties, and corridor-style wet room installations where a standard wider tray simply won't fit.

Despite the slim profile, the Braddan delivers a full-length showering experience. Made from durable GRP with integral reinforcement, it supports up to 190.5kg (30 stone) and features a slip-resistant surface as standard. At just 40mm high, it can be surface mounted for a low step-in threshold, semi-recessed for a 20mm threshold, or fully recessed into the floor for complete level access.

No under-tray foaming is required, keeping installation clean and straightforward. The non-handed design works for both left and right-hand layouts. Tiling upstands are included as standard to ensure a watertight finish between the tray and wall tiles. Optional 20mm and 40mm ramp kits are available for semi-recessed or surface-mounted installations.

This pack includes a TDTW 50 White ABS Plastic Gravity Waste (Code 25126), which features a built-in filter, secure 50mm threaded fitting, and 124mm depth below tray.

Key Specifications:

• Size: 1200 × 650mm
• Material: GRP (Glass Reinforced Plastic)
• Height: 40mm
• Threshold: 0mm (recessed), 20mm (semi), or 40mm (surface mounted)
• Waste Position: Central
• Fall to Waste: 35mm
• Load Capacity: 190.5kg (30 stone)
• Floor Types: Timber, concrete, screeded
• Tiling Upstands: Included
• Warranty: Lifetime guarantee

What's Included:

• 1 × AKW Braddan 1200×650mm Shower Tray (Code 16360)
• 1 × TDTW 50 White ABS Plastic Gravity Waste (Code 25126)

Frequently Asked Questions

Who is the 1200x650mm Braddan best suited for? It's ideal for narrow spaces where a standard 700mm or 800mm wide tray won't fit. The 650mm depth is the slimmest in the Braddan range, making it the go-to choice for tight bathrooms while still providing a 1200mm showering length.

Can this tray be used for full level access? Yes — when fully recessed into the floor it creates a 0mm threshold, suitable for wheelchair users and DDA-compliant installations.

Is under-tray foaming required? No, the Braddan's design eliminates the need for under-tray foaming entirely.

Can I fit a different waste to this tray? Yes. The Braddan is compatible with AKW's full range of gravity and pumped waste options. An upward discharge pumped waste is also available for installations where the floor cannot be breached.

Is it compatible with AKW shower screens? The 1200x650mm Braddan is compatible with AKW Standard, Silverdale, Sliding, Level Best, and Larenco screen ranges.

What is the warranty? The AKW Braddan carries a lifetime guarantee (terms and conditions apply).

📄 Download AKW Braddan Specification Sheet
