AKW Braddan 1300x700mm Level Access Shower Tray & Gravity Waste (16013W)

AKW Braddan 1300x700mm Level Access Shower Tray with Gravity Waste (Code 16013W)

The AKW Braddan 1300x700mm is a long, narrow shower tray that excels in bathrooms where wall length is generous but floor width remains restricted. At 1300mm long and 700mm wide, it provides an excellent showering length for taller users and accessibility installations, while the 700mm depth keeps the overall footprint manageable in narrower rooms, corridors, and adapted en-suites.

Made from durable GRP with integral reinforcement, the Braddan supports up to 190.5kg (30 stone) and features a slip-resistant surface as standard. At just 40mm high, it can be surface mounted for a low step-in threshold, semi-recessed for a 20mm threshold, or fully recessed into the floor for complete level access — making it suitable for the full range of domestic and accessibility projects.

No under-tray foaming is required, keeping installation clean and straightforward. The non-handed design works for both left and right-hand layouts. Tiling upstands are included as standard to ensure a watertight finish between the tray and wall tiles. Optional 20mm and 40mm ramp kits are available for semi-recessed or surface-mounted installations.

This pack includes a TDTW 50 White ABS Plastic Gravity Waste (Code 25126), which features a built-in filter, secure 50mm threaded fitting, and 124mm depth below tray.

Key Specifications:

• Size: 1300 × 700mm
• Material: GRP (Glass Reinforced Plastic)
• Height: 40mm
• Threshold: 0mm (recessed), 20mm (semi), or 40mm (surface mounted)
• Waste Position: Central
• Fall to Waste: 35mm
• Load Capacity: 190.5kg (30 stone)
• Floor Types: Timber, concrete, screeded
• Tiling Upstands: Included
• Warranty: Lifetime guarantee

What's Included:

• 1 × AKW Braddan 1300×700mm Shower Tray (Code 16013)
• 1 × TDTW 50 White ABS Plastic Gravity Waste (Code 25126)

Frequently Asked Questions

Who is the 1300x700mm Braddan best suited for? It's a great choice for bathrooms with a long wall run but limited width — the 1300mm length is ideal for taller users or where a carer needs to assist from the end, while the 700mm depth minimises the floor space required. A popular option for corridor bathrooms and accessibility adaptations in older properties.

Can this tray be used for full level access? Yes — when fully recessed into the floor it creates a 0mm threshold, suitable for wheelchair users and DDA-compliant installations.

Is under-tray foaming required? No, the Braddan's design eliminates the need for under-tray foaming entirely.

Can I fit a different waste to this tray? Yes. The Braddan is compatible with AKW's full range of gravity and pumped waste options. An upward discharge pumped waste is also available for installations where the floor cannot be breached.

Is it compatible with AKW shower screens? The 1300x700mm Braddan is compatible with AKW Standard, Silverdale, Sliding, Level Best, and Larenco screen ranges.

What is the warranty? The AKW Braddan carries a lifetime guarantee (terms and conditions apply).

📄 Download AKW Braddan Specification Sheet
