AKW Braddan 1420x700mm Level Access Shower Tray & Gravity Waste (16022W)

AKW Braddan 1420x700mm Level Access Shower Tray with Gravity Waste (Code 16022W)

The AKW Braddan 1420x700mm is one of the longest narrow trays in the Braddan range, offering an exceptional showering length in a compact 700mm footprint. At 1420mm long, it is particularly well suited to taller users, purpose-built accessible wet rooms, and care environments where a long showering run is needed without widening the overall floor area. The slim 700mm depth makes it ideal for corridor-style bathrooms and narrow adapted spaces.

Made from durable GRP with integral reinforcement, the Braddan supports up to 190.5kg (30 stone) and features a slip-resistant surface as standard. At just 40mm high, it can be surface mounted for a low step-in threshold, semi-recessed for a 20mm threshold, or fully recessed into the floor for complete level access — making it suitable for the full range of domestic and accessibility projects.

No under-tray foaming is required, keeping installation clean and straightforward. The non-handed design works for both left and right-hand layouts. Tiling upstands are included as standard to ensure a watertight finish between the tray and wall tiles. Optional 20mm and 40mm ramp kits are available for semi-recessed or surface-mounted installations.

This pack includes a TDTW 50 White ABS Plastic Gravity Waste (Code 25126), which features a built-in filter, secure 50mm threaded fitting, and 124mm depth below tray.

Key Specifications:

• Size: 1420 × 700mm
• Material: GRP (Glass Reinforced Plastic)
• Height: 40mm
• Threshold: 0mm (recessed), 20mm (semi), or 40mm (surface mounted)
• Waste Position: Central
• Fall to Waste: 35mm
• Load Capacity: 190.5kg (30 stone)
• Floor Types: Timber, concrete, screeded
• Tiling Upstands: Included
• Warranty: Lifetime guarantee

What's Included:

• 1 × AKW Braddan 1420×700mm Shower Tray (Code 16022)
• 1 × TDTW 50 White ABS Plastic Gravity Waste (Code 25126)

Frequently Asked Questions

How does the 1420x700mm compare to the 1300x700mm Braddan? Both are narrow 700mm-depth trays, but the 1420mm adds an extra 120mm of showering length — useful for taller users or where the layout demands a longer run. If your space allows, the 1420mm gives you noticeably more room to move without increasing the width.

Can this tray be used for full level access? Yes — when fully recessed into the floor it creates a 0mm threshold, suitable for wheelchair users and DDA-compliant installations.

Is under-tray foaming required? No, the Braddan's design eliminates the need for under-tray foaming entirely.

Can I fit a different waste to this tray? Yes. The Braddan is compatible with AKW's full range of gravity and pumped waste options. An upward discharge pumped waste is also available for installations where the floor cannot be breached.

Is it compatible with AKW shower screens? The 1420x700mm Braddan is compatible with AKW Standard, Silverdale, Sliding, Level Best, and Larenco screen ranges.

What is the warranty? The AKW Braddan carries a lifetime guarantee (terms and conditions apply).
