AKW Braddan 820x820mm Level Access Shower Tray & Gravity Waste (16470W)

AKW Braddan 820x820mm Level Access Shower Tray with Gravity Waste (Code 16470W)

The AKW Braddan 820x820mm is a compact square shower tray offering just a little more space than the 800x800mm — a popular choice where a standard 800mm square tray doesn't quite fit but a larger rectangular tray would be too big. Like all Braddan trays, it's designed for accessible, safe, and easy-to-install showering environments.

Made from durable GRP with integral reinforcement, the Braddan supports up to 190.5kg (30 stone) and features a slip-resistant surface as standard. At just 40mm high, it can be surface mounted for a low step-in threshold, semi-recessed for a 20mm threshold, or fully recessed into the floor for complete level access.

No under-tray foaming is required, keeping installation clean and quick. The non-handed design works for both left and right-hand layouts. Tiling upstands are included as standard to ensure a watertight finish between the tray and wall tiles. Optional 20mm and 40mm ramp kits are available for semi-recessed or surface-mounted installations.

This pack includes a TDTW 50 White ABS Plastic Gravity Waste (Code 25126), which features a built-in filter, secure 50mm threaded fitting, and 124mm depth below tray.

Key Specifications:

• Size: 820 × 820mm
• Material: GRP (Glass Reinforced Plastic)
• Height: 40mm
• Threshold: 0mm (recessed), 20mm (semi), or 40mm (surface mounted)
• Waste Position: Central
• Fall to Waste: 35mm
• Load Capacity: 190.5kg (30 stone)
• Floor Types: Timber, concrete, screeded
• Tiling Upstands: Included
• Warranty: Lifetime guarantee

What's Included:

• 1 × AKW Braddan 820×820mm Shower Tray (Code 16470)
• 1 × TDTW 50 White ABS Plastic Gravity Waste (Code 25126)

Frequently Asked Questions

What's the difference between the 800x800mm and 820x820mm Braddan? The 820x820mm is 20mm larger in each direction — a small but useful difference when bathroom space is tight and a standard 800mm tray falls just short of fitting your enclosure.

Can this tray be used for full level access? Yes — when fully recessed into the floor it creates a 0mm threshold, suitable for wheelchair users and DDA-compliant installations.

Is under-tray foaming required? No, the Braddan's design removes the need for under-tray foaming entirely.

Can I fit a different waste to this tray? Yes. The Braddan is compatible with AKW's gravity and pumped waste options. An upward discharge pumped waste is also available for installations where the floor cannot be breached.

Is it compatible with AKW shower screens? The 820x820mm Braddan is compatible with AKW Standard and Silverdale screen ranges, as well as the Level Best screen range.

What is the warranty? The AKW Braddan carries a lifetime guarantee (terms and conditions apply).

Download AKW Braddan Specification Sheet
