Nuie Revive Vertical Single Panel Radiator – 1785 x 413mm, 1800 x 413mm & 1800 x 499mm (All Sizes)

Nuie Revive Vertical Single Panel Radiator – 1785 x 413mm, 1800 x 413mm & 1800 x 499mm (All Sizes)

The Nuie Revive Vertical Single Panel Radiator is a central heating radiator. Choose from 3 sizes and 2 colours using the options above.

Choose a radiator by heat output as well as size – the heat output (in BTU or watts) needs to suit the size of the room, how well it's insulated and the number of windows. Valves are sold separately.

Product Codes

Choose your options above and the code for that option shows under the product title.

Key Features

• Steel construction
• 5 year guarantee from Nuie

Before You Buy

• Check the heat output (BTU) suits the size of the room.
• Check your pipe positions and the valves you need – valves are usually sold separately.
• Radiators should be fitted by a competent plumber.

Looking After It

Clean with warm soapy water and a soft cloth, then dry. Avoid abrasive creams, scouring pads and bleach or limescale removers, which can damage the finish.

Specifications

• Range: Nuie Revive
• Material: Steel
• Mounting: Wall Hung
• Heat output ΔT60 (BTU): 2741 / 3251
• Heat output ΔT50 (BTU): 2164 / 2566
• Heat output ΔT30 (BTU): 1195 / 1345
• Pipe centres (mm): 503 / 589
• Projection from wall (mm): 110 / 205 / 90
• Orientation: Vertical
• Guarantee: 5 years

Codes, Sizes, Barcodes and Data Sheets

Delivery

Delivered to UK mainland addresses, usually within 2 working days.
