Snug Electric Underfloor Heating Mat 200w/m²

Snug Mat 200W/m² Electric Underfloor Heating Mat

The Snug Mat 200W/m² Underfloor Heating Mat is a high-output electric floor heating system engineered to act as the primary or sole heat source in a room. With its powerful heat output and ultra-slim profile, it delivers fast, even warmth while maintaining minimal floor build-up.

This triple-insulated Class 2 heating mat features a twin-conductor, single-connection cable securely woven into a fully adhesive fabric mesh. The mesh ensures the mat stays flat as soon as it is rolled out, making installation quick, accurate and hassle-free. At only 2mm thick, it is one of the thinnest high-output underfloor heating mats available.

Manufactured in a wide range of ready-made sizes from 1m² to 15m², the Snug Mat 200 offers excellent flexibility for installers and homeowners alike. With the supply lead positioned at one end only, it is easy to plan, cut and lay, making it suitable for both small spaces and large open areas.

Ideal for use in lounges, kitchens, conservatories and open-plan living areas, the Snug Mat 200 can be installed beneath ceramic tiles, porcelain, stone, slate, terracotta, limestone and marble, providing reliable and consistent warmth throughout the room.

Key Features & Benefits

• High-power 200W/m² output for fast, effective heating

• Designed to be the single or primary heat source

• Ideal for living rooms, kitchens, conservatories and large areas

• Compatible with tile, stone, marble, slate and natural flooring

• Ultra-thin 2mm profile – minimal impact on floor height

• Fully adhesive-backed mesh for easy installation

• Available in sizes from 1m² to 15m²

• 3m cold lead for flexible thermostat positioning

• Durable FEP (Fluoropolymer) cable insulation

• Exceeds international safety and quality standards

• Single connection cable for simple wiring

• Zero electromagnetic fields

• Lifetime warranty on the heating cable

Technical Specifications

• Output: 200W/m²

• Cable Thickness: 2mm

• Voltage: 230V

• Mat Width: 500mm

• Maximum Temperature Output: +80°C

• Connection Type: One-sided connection

• Protection: Class 1 with RCD protection

• Cable Spacing: 80mm

• Colour: Blue

• Warranty: Lifetime cable warranty

Product Options & Electrical Data

200MAT1
Coverage Area: 1m²
Total Output: 200W
Resistance: 265Ω

200MAT1.5
Coverage Area: 1.5m²
Total Output: 300W
Resistance: 176Ω

200MAT2
Coverage Area: 2m²
Total Output: 400W
Resistance: 132Ω

200MAT2.5
Coverage Area: 2.5m²
Total Output: 500W
Resistance: 105Ω

200MAT3
Coverage Area: 3m²
Total Output: 600W
Resistance: 88Ω

200MAT4
Coverage Area: 4m²
Total Output: 800W
Resistance: 66Ω

200MAT5
Coverage Area: 5m²
Total Output: 1000W
Resistance: 53Ω

200MAT6
Coverage Area: 6m²
Total Output: 1200W
Resistance: 44Ω

200MAT7
Coverage Area: 7m²
Total Output: 1400W
Resistance: 38Ω

200MAT8
Coverage Area: 8m²
Total Output: 1600W
Resistance: 33Ω

200MAT9
Coverage Area: 9m²
Total Output: 1800W
Resistance: 29Ω

200MAT10
Coverage Area: 10m²
Total Output: 2000W
Resistance: 26Ω

200MAT12
Coverage Area: 12m²
Total Output: 2400W
Resistance: 22Ω

200MAT15
Coverage Area: 15m²
Total Output: 3000W
Resistance: 17Ω
